2.8.4. Profile Mode Parameters
Parameter Name Modbus
Address
(Dec) Modbus
Address
(Hex) Access
R/W Notes
Currently
Selected Profile 8243 0x2033 R/W Value between 0 and 63
Currently Active
Segment 8244 0x2034 RO Value between 0 and 255
Current Setpoint 8256 0x2040 RO
Currently
Running
Segment Type 8258 0x2042 RO 0 = None
1 = Ramp Up
2 = Step
3 = Dwell
4 = Hold
5 = Loop
6 = Join
7 = End
8 = Ramp Down
Start Delay Time 8233 0x2029 RO Value in seconds. The current start delay time
remaining
Current Time of
the active
segment 8237 0x202D RO Value in seconds. The amount of time the
segment has been running
Current
Remaining Time
of segment 8238 0x202E RO Value in seconds. The amount of time remaining
for the active segment.
Current Time of
the running
Profile 8235 0x202B RO Value in seconds. The amount of time the profile
has been running.
Current
Remaining
Profile Time 8236 0x202C RO Value in seconds. The amount of time remaining
for the complete profile.
Total Hold Time 8239 0x202F RO Value in seconds. The total amount of time the
profile has been held for.
Profile Mode
Relay Status 2170 0x087A RO Bit 0 = Relay 1
Bit 1 = Relay 2
Bit 2 = Relay 3
Bit 3 = Relay 4
Bit 4 = Relay 5
Event 1 Status 8249 0x2039 RO 0 = Inactive
1 = Active
Event 2 Status 8250 0x203A RO 0 = Inactive
1 = Active
Event 3 Status 8251 0x203B RO 0 = Inactive
1 = Active
Event 4 Status 8252 0x203C RO 0 = Inactive
1 = Active
Profile Selection 8243 0x2033 R/W Value between 0 and 63 to select the profile to run
