Parameter Name
Modbus
Address
(Dec)
Modbus
Address
(Hex)
Access
R/W
Notes
Manual Mode
Relay 4
8252
0x203C
R/W
0 = Off
1 = On
2.8.3. Timer Mode Parameters
Parameter Name
Modbus
Address
(Dec)
Modbus
Address
(Hex)
Access
R/W
Notes
Timer Mode
Recovery
8275
0x2053
R/W
0 = Control Off
1 = Restart Timer
2 = Continue Timer
Timer Mode
Recovery Time
8276
0x2054
R/W
Value in seconds
Timer Mode Auto
Hold Value
8272
0x2050
R/W
Timer Mode
Status
8282
0x205A
RO
0 = Mode Stopped
1 = Mode Running
Timer Mode
Relay Status
2170
0x087A
RO
Bit 0 = Relay 1
Bit 1 = Relay 2
Bit 2 = Relay 3
Bit 3 = Relay 4
Bit 4 = Relay 5
Timer Mode
Control
8284
0x205C
R/W
0 = Stop Timer
1 = Start Timer
3 = Waiting for Command
Timer Time
8270
0x204E
R/W
Time in seconds
Current
Remaining Time
of timer
8238
0x202E
RO
Value in seconds. The amount of time remaining
for the active segment.
Timer Mode
Control Setpoint
3960
0x0F78
R/W
Timer Mode
Relay 1
8249
0x2039
R/W
0 = Off
1 = On
Timer Mode
Relay 2
8250
0x203A
R/W
0 = Off
1 = On
Timer Mode
Relay 3
8251
0x203B
R/W
0 = Off
1 = On
Timer Mode
Relay 4
8252
0x203C
R/W
0 = Off
1 = On
