CMX
DL+
High Performance Material & Coating Thickness Gauge
45
In this first example the transducer was automatically identified:
Probe Automatically Recognized
1) Press the OK key once to use the identified probe, or ESC to display a list of
optional transducers. Note: if the CMX
DL+
recognizes a specific
transducer, the user should always select OK to use the identified probe.
The only time an alternative probe should be selected from a list is if the
user switched probes following initial power up and recognition, or the
CMX
DL+
has somehow identified the probe in error..
2) Assuming the CMX
DL+
recognized the probe and the OK key was pressed,
the CMX
DL+
will advance to a Zero Probe menu. If the transducer was
identified as a special transducer capable of measuring coating thickness, a
menu will be displayed allowing the user the ability to toggle the coating
thickness display on/off as follows :
