Dakota Ultrasonics CMX DL plus - Manual (Page 119)

CMX
DL+
High Performance Material & Coating Thickness Gauge
115
Setting the Differential Value
1) Assuming DIFFERENTIAL has been enabled and a value is being displayed
to the right of the DIFFERENTIAL label, press the ENTER key to display the
Digits Edit Box.
2) Press the UP and DOWN arrow keys to scroll the highlighted value.
3) Press the LEFT and RIGHT arrow keys to scroll the digit locations.
4) Repeat steps 2 & 3 until the DIFFERENTIAL value is correctly displayed.
5) Press the OK key to set the DIFFERENTIAL value and return to the menu
screen.
6) Finally, press the MEAS key to return to the measurement screen and begin
taking readings.
10.5 Brightness (color version only)
The CMX
DL+
color version is equipped with a brightness feature to adjust the display
visibility and optimize battery life. It has an arbitrary scale with a values from 1 -20,
with 20 representing the brightest setting. The procedures for adjusting the
brightness are outlined below:
