Dakota Ultrasonics
32
AUTO FIND: Automatically locates the detection point if the measurement is out of
the viewable display area. Refer to page 109 for further info.
SCAN MODE: This function enables a hi speed scan mode that increases the
overall sample rate from 65 to 200 measurements per second, depending on the
current measurement mode used. Refer to page 109 for further info.
ALARM: Toggles alarm mode on, off, or audible . Refer to page 111 for further info.
ALARM HIGH: Gives the user the ability to set the HI limit parameter. If the
measurement exceeds this value, a red light will illuminate and sound the internal
beeper. Refer to page 111 for further info.
ALARM LOW: Gives the user the ability to set the LO limit parameter. If the
measurement falls below this value, a red light will illuminate and sound the internal
beeper. Refer to page 111 for further info.
DIFFERENTIAL: Gives the user the ability to set a nominal value and the CMX
DL+
will display +/- the difference from the nominal value entered. Refer to page 113 for
further info.
3.12 XFER (transfer) – Menu
BACKUP SETUPS: Enables the user the ability to backup the setups currently
stored in the CMX
DL+
to a PC via RS232 port. Refer the help section of the CMX
DL+
DakView software for a complete electronic manual.
RESTORE SETUPS: Enables the user the ability to restore the setups currently
saved on a PC to an CMX
DL+
via RS232 port. Refer the help section of the CMX
DL+
DakView software for a complete electronic manual.
BACKUP DATA: Enables the user the ability to backup grids or sequential log files
currently stored in the CMX
DL+
to a PC via RS232 port. Refer the help section of the
CMX
DL+
DakView software for a complete electronic manual.
RESTORE DATA: Enables the user the ability to restore grids or sequential log files
currently saved on a PC to an CMX
DL+
via RS232 port. Refer the help section of the
CMX
DL+
DakView software for a complete electronic manual.
ABOUT: Provides the user with Dakota Ultrasonics contact information and the
CMX
DL+ software version. Refer the Dakota Ultrasonics web site for information on
the latest firmware versions available for download.
