Dakota Ultrasonics CMX DL plus - Manual (Page 38)

Dakota Ultrasonics
34
The ENTER key is used in the overall menu selection process, to activate list and
edit boxes, display and save measurements to grid or sequential files locations.
3.19 MULTI MODE Key
The MULTI MODE key opens a measurement mode screen, listing all the modes that
are available to the transducer specifically selected, or autodetected. The modes can
be all or a combination of the entire set of modes the CMX
DL+
offers, depending on
which transducer is being used as follows: Coating Off (P-E), Coating On (PECT),
Temp Comp (PETP), Thru Coat (E-E), Thru Coat Verify (E-EV), and Coating Only
(CT).
3.20 ON/OFF Key
The ON/OFF key simply powers the unit either ON or OFF. Note: Unit will
automatically power off when idle for 5 minutes. All current settings are automatically
saved prior to powering off.
