Page 54
54
APPENDIx
O.
Counter Spring Kit
Counter Spring Replacement Kit
08780641
Parts List, Counter Spring Replacement Kit
08780641
ITEm
PART NO
DESCRIPTION
REQuIRED
QTY
kIT
QTY
1
02288583
Capsrw M06-1.0x 10 BHSS 18-8
2
1
2
02288588
Flatwshr M06-Narr ST CZ
2
1
3
02288639
Cap, Vinyl .75id-.88od-1.00 Blk
2
1
4
02288677
Sensor, Pickup-Turck Picoprox
1
5
02288721
Spring, Comprss .063-0.600-2.50
2
1
6
02288727
Shaft, Counter (assy) LW FO Blwr
1
7
02290215
Clamp, Cable Counter-Assy
1
8
08780022
Retainer, Spring-Cable Clamp
1
1
9
08780090
Pad, Guide-Rear Cable Entry
1
10
08780097
Cordset Assy 2pin W/Connectors
2
11
08780135
Panel, Control-Touch LW Blower
1
12
08780193
Cordset, Rear Sensor LW Blower
1
13
08781011
Cordset, Front Sensor LW Blower
1
14
08781026
Cordset, Transducer LW Blower
1
ITEMS 4, 6, 7, 9, 10, 11, 12, 13, 14 ARE NOT INCLUDED IN KIT 08780641
