50
APPENDIx
K.
Clamp Adjustment Kit
Parts List, Clamp Adjustment Replacement Kit
08780637
Clamp Adjustment Replacement Kit
08780637
ITEm PART NO DESCRIPTION
REQuIRED
QTY
kIT
QTY
1 02240800 Capsrw, #10-24 x 0.50 BHSS 18-8 1 1
2 02288610 Cylinder, Lift-Pnuematic Chrgd 1
3 02288644 Lever, Ball Knob 10mm 08mm Thr 2 2
4 02288646 Zerk, Grease, 6mm-1.0 Straight 1 1
5 02289031 Bearing , Thr 1.265-2.0-0.062 1 1
6 02290172 Washer, Fender #10-1.00-.113 1 1
7 08780081 Shaft, Tension Adjustment 1 1
8 08780106 Body, Handle-Clamp Cylinder 1 1
9 08780661 Bushing, Clamp Stopper 1 1
ITEM 2 IS NOT INCLUDED IN KIT 08780637
