SPECIFICATIONS
For
Underground Medium Voltage Cable Pulling System
For
your
bid
to
be
considered,
documentation
of
adherence
to
the
following
specified
items
must
be
supplied
with
bid:
1.0 GENERAL DESCRIPTION
1.1 The pulling system shall have a 7500 lb pulling capacity with hydraulically driven capstan
bullwheels.
1.2 The unit shall have a constant pulling capacity of 7500 lbs w/maximum speed of 175
feet/minute
and
be
equipped
with
footage
counter
and
dynamometer
to
meter
actual
conductor
pulling
lengths
and
tensions.
1.3 The
system
shall
be
powered
by
a
liquid
cooled,
diesel
engine
(minimum
34
HP).
1.4 The
unit
shall
have
an
electronic
information
center
which
provides
digital
readout
of
pulling
tensions,
pulling
distance
and
hydraulic
pressures.
It
should
also
allow
for
preset
of
pull
tension
with
automatic
shut
off,
if
exceeded.
1.5 The unit shall have an infinitely variable joystick control for on demand payout/pullback -‐
eliminating
cable
storage
reel
over
spin
(backlash)
-‐
from
both
an
onboard
control
panel
and
a
tethered
remote
control.
1.6 The trailer shall be constructed of rugged high strength steel channel and tubing –
welded
solid
for
rigidity
and
shall
be
equipped
with
an
adjustable
pintle
eye,
mechanical
leveling
jacks,
tool
box,
electric
road
brakes
and
DOT
standard
lighting.
2.0 GENERAL SPECIFICATIONS
2.1 Engine
(Puller):
34HP,
Four
Cylinder,
Liquid
Cooled
Diesel
w/Electric
Start
2.2 Fuel
Capacity:
18
Gallons
2.3 Totally
Hydraulically
Driven
Puller
w/40
GPM
Pump
&
Motor
w/20
Gallon
Filtered
Hydraulic Fluid Reservoir
2.4 Auxiliary
Hydraulic
Tool
Circuit:
7
GPM
@
2000
PSI
(for
Hand
Tools
/
Pumps
/
etc)
2.5 Bullwheels:
Twin
Capstan
(8.5”
x
6
Groove)
2.6 Pulling
Speed:
175
fpm
(maximum)
@
7500
lbs
2.7 Hydraulic
Boom:
Boom
Shall
Hydraulically
Raise/Lower
and
Pivot
Left/Right
At
Least
Fifteen Degrees
2.8 Pulling Rope: 2600’ x 3/8” Anti-‐Twist, Braided Style Cable Specifically Designed for Pulling
Operations
–
Allows
for
Industry
Standard
Swivel
Usage
–
Locking
Connectors
Not
Required
2.9 Pulling
Cable
Level
Wind:
Mechanical
(Brass
Finger
in
Grooved
Steel
Shaft)
2.10 Control
Panel:
Located
at
Optimal
Height
for
Operator
Safety
and
Ease
of
Use
w/Complete
Engine
Instrumentation,
Joystick
Pulling
Controls,
Emergency
Stop
Switch
and
Dynamometer
for
Presetting
and
Monitoring
Pulling
Tensions.
2.11 Footage
Counter:
Monitors
Actual
Footage
of
Cable
in
Both
Pay
Out
and
Pull
Back
Modes.
2.12 Remote
Control:
Tethered
Remote
Control
w/
25’
Range
w/Joystick
Control
for
Payout/Pullback and Emergency Stop Switch.
