4
1.
General Information
2.
The Condux Fiber Optic Cable Puller is a hydraulic pulling machine designed for fiber optic cable placement.
It offers bi-directional pulling and load-sensing capabilities. The system uses a hydraulic motor and capstan
with an electronic tension control system.
The tension control system uses an electronic load cell to measure the actual torque at the puller’s motor.
Combining this torque value with the capstan’s diameter ensures accurate tension monitoring. The system’s
design gives the operator complete control over the equipment. It can be set to a maximum tension limit that
will stop the puller and give both audible and visual alarms if the tension limit is exceeded during the pull.
A digital chart recorder continuously records the pulling tensions during operation. The power pack or the
vehicle’s 12 Volt DC power point energizes the electronic tension control system.
The puller comes standard with a variable speed foot control and hoses to the puller motor, an adjustable flow
control valve for adjusting maximum pulling speed, and a manually adjustable pressure relief valve for adjust-
ing the maximum pressure supplied to the
hydraulic motor.
Technical Specifications
A. HYDRAULICS
• Open center system
• Pressure: 2000-2500 psi (137-172 bar)
• Flow: 6-10 gpm (22.7-37.9 lpm)
• Relief valve setting: 2250 psi (155 bar)
• Reservoir capacity: 12 gallons (45.5 l)
• Filtration: 10 micron nominal
• Hydraulic Fluid: Petroleum-based, anti-wear properties, viscosity’s over 140
• Horsepower: 8 hp (5.97 kW)
b. POwER REqUIREmENTS
• 12 volts direct current (DC) for electronic control box
C. DIgITAL CHART RECORDER
• Variable Sample Rate
• 256MB Compact Flash Card
• Download directly to computer via USB connection
D. FACTORY PRESETS
• Relief Valve:
1,783 lbs. (7,930 N) line tension on the 12" (305 mm) diameter capstan
700 lbs. (3,113 N) line tension on the 30" (762 mm) diameter capstan
428 lbs. (1,903 N) line tension on the 42" (1,067 mm) diameter capstan
• Electronic Control Box: 650 lbs. (2,891 N) line tension, any capstan
E. mAXImUm PULLINg CAPACITIES
• 2,000 lbs. (8,896 N) line tension on the 12" (305 mm) diameter capstan
• 1,000 lbs. (4,448 N) line tension on the 30" (762 mm) diameter capstan
• 600 lbs. (2,669 N) line tension on the 42" (1,067 mm) diameter capstan
