E. PARTS LIST FOR FOOT CONTROL vALvE ASSEmbLY
ITEm PART NO.
DESCRIPTION
qTY
02272900
FOOT VALVE SEAL KIT
1
1
02021400
CAPSRW 0.25-20X0.75 HHSTGR5 CZ
1
2
02053800
FTG,HYD 08-NPT_M ;08-JIC
8
3
02102000
FLATWSHR 0.25 TYPEA-WIDE ST CZ
2
4
02202100
FTG,HYD 08-NPT_M ;08-NPT_F 90’
8
5
02234300
CAPSRW 0.25-20X1.00 SHSTALY PL
2
6
02235000
TERMINAL,BUTT CONNCTOR 22-18GA
2
7
02238700
CAPSRW 0.25-20X1.75 SHSTALY PL
3
8
02240800
CAPSRW #10-24X0.50 BHSS 18-8 2
28
9
02254900
FTG,HYD 12-NPT_M; 08-NPT_F
4
10
02260000
COUPLER,FEMALE-FLAT FACE
2
11
02260100
COUPLER,MALE-FLAT FACE
1
12
02260200
CAP,DUST(MALE FLAT FACE CPLRS)
3
13
02260201
CAP,DUST(FEM FLAT FACE CPLRS)
1
14
02263200
LABEL,PRESS ADJ-BASIC FO PULLR
1
15
02267800
CONNECTOR,FEM-2 CONT-W/48” WIRE
3
16
02269600
FTG,HYD 08 O-RING;08-NPT_M
1
17
02269605
LABEL,WARNING-HYD FLD 1.5X4.5
1
18
02269607
LABEL,WARNING-READ MAN 1.5X4.5
2
19
02269608
LABEL,PRESSURE 1.5X3(HYD PROD)
1
20
02269609
LABEL,RETURN 1.5X3 (HYD PROD)
1
21
02269612
LABEL,DO NOT FORCE-FOOT CONTRL
1
22
02269700
HOSE 04X 15.00-04SW-04FPT 3000
1
23
02269800
GAUGE,OIL PRES 0-3000 CTR-CLMP
1
24
02269900
FTG,HYD 08-NPT_M;08-NPT_M 2.50
1
25
02270000
LABEL,PULL TENSION-BSC FO PLLR
1
26
02290105
RECEPTACLE,3PIN BULKHEAD MALE
2
27
02290109
CAPSRW 0.25-20X0.75 SHSTALY PL
1
28
08089753
LABEL,CONDUX 1.75 X 5.50 WHITE
1
29
08674733
VALVE,CONTROL W/PEDAL-SHPP
1
30
08675159
BODY,SPOOL STOP-LOWER
1
31
08675160
BODY,SPOOL STOP-UPPER
1
32
08675191
KNOB,FLOW ADJUSTMENT
1
33
08675193
KNOB,STEEL 2.00 OD 3/8-16 FEM
1
34
08675323
MOUNT,CONTROL VALVE-BSC FO PL
1
35
08675324
GUARD,TOP-FOOT CONTROL-BFOP
1
36
08675325
GUARD,RH SIDE-FOOT CNTRL-BFOP
1
37
08675334
GUARD,LH SIDE-FOOT CNTRL-BFOP
1
38
08675340
PLATE,BASE-FT CTRL-WELD + MACH
1
39
08675350
GUARD,FOOT CONTROL-FO PULLER
1
40
08675856
MANIFOLD SUBASSY-LW F/O PULL
1
41
08675884
SUPPORT,MANIFOLD-LW F/O PULLER
2
42
12000901
FLATWSHR 0.37 TYPEA-WIDE ST CZ
4
43
12004700
CAPSRW 0.37-16X0.75 HHSTGR5 CZ
4
44
12013700
NUT 0.25-20 NYLOC ST GR5 CZ
3
