25
C. PARTS LIST FOR PULLER ASSEmbLY
ITEm PART NO. DESCRIPTION qTY
1 02001600 CAPSRW 0.50-13X1.25 HHSTGR5 CZ 2
2 02004500 LOCKWSHR 0.37 REGULAR ST CZ 4
3 02020701 CAPSRW 0.37-16X1.00 HHSTGR5 CZ 4
4 02021501 LOCKWSHR 0.25 REGULAR ST CZ 2
5 02026200 CAPSRW 0.62-11X2.00 HHSTGR5 CZ 4
6 02027500 NUT 0.62-11 NYLOC ST GR5 CZ 4
7 02114700 FTG,HYD 08 O-RING;08-JIC 45’ 2
8 02190300 O-RING, .103CS- .487ID BUNA-N 2
9 02231400 CAPSRW 0.25-20X0.62 SHSTALY PL 2
10 02253900 CAPSRW 0.50-13X1.00 SHSTALY PL 2
11 02254600 FTG,HYD 06 O-RING;PLUG-HEXSOCK 1
12 02260000 COUPLER,QD-FEMALE FF 1/2IN NPT 2
13 02260201 CAP,DUST (FEM FLAT FACE CPLRS) 2
14 02268700 SCREW,SHOULDER 0.375 DIA- 1.25 2 *
15 02269605 LABEL,WARNING-HYD FLD 1.5X4.5 1
16 02269607 LABEL,WARNING-READ MAN 1.5X4.5 1
17 02269610 LABEL,WARNING-CBLE TEN 1.5X4.5 1
18 02270200 CAPSRW 0.31-18X2.00 SHSTALY PL 4
19 02272300 NUT 0.37-24 HJAM ST GR2 CZ 2 *
20 02272400 END,ROD SELF-ALIGNING NF6 2 *
21 02272500 BEARING,DGB 55 ID 72MM SLD 2
22 02288503 FTG,HYD 08 O-RING;10-JIC_M 90’ 2
23 02288504 HOSE 08X 13.0-08SW -10SW 3K 1
24 02288504 HOSE 08X 13.0-08SW -10SW 3K 1
25 08089753 LABEL,CONDUX 1.75 X 5.50 WHITE 1
26 08675318 MOTOR,HYD-BASIC FO PULLER 1
27 08675830 GEARBOX, ASSY-PLANETARY 1
28 08675831 FRAME,PULLER (WELD)-LW F/O PULL 1
29 08675841 GUARD,MOTOR (WELD)-LW F/O PULL 1
30 08675848 MANIFOLD,HYD MOTOR-LW F/O PULL 1
31 08675850 HOUSING,BEARING-LW F/O PULL 1
32 08675851 SUPPORT,HYD MOTOR ASSY-LW F/O 1
33 08675854 NUT,BEARING-LW F/O PUL 1
34 08675860 ROD,SPACER-LW FO PULL W/O ELEC 1 *
35 08675922 KIT,LOADCELL-LW FO PULLER-5PIN 1
36 12002300 NUT 0.31-18 NYLOC ST GR5 CZ 1 *
37 12003900 FTG,HYD 08-NPT_M ;08-NPT_M 2
38 12010600 LOCKWSHR 0.50 REGULAR ST CZ 2
* PARTS ARE REPLACED BY LOADCELL KIT (08675922) WHEN ELECTRONICS ARE USED
