Important: Always read and follow operating instructions. • 3
CAUTION
Replace any damaged or missing safety
decals. They are available from COATS, (800)
688-6359.
1 Tower — Support for horizontal and vertical slides,
also air storage tank.
2 Air Gauge — Registers tire pressure when air chuck
is attached to valve stem and inflation pedal is released.
3 Inflation Pedal — Two-position pedal that allows
inflation of tires through air hose and clip-on chuck.
4 Clamp Control Pedal — Three-position pedal that
opens, holds or closes rim clamps.
5 Table Top Pedal — Three-position pedal that controls
rotation of table top (forward, off, reverse).
6 Bead Loosener Control Pedal — Controls operation
of bead loosener shoe.
7 Table Top — Rotating chuck for tire changing.
8 Motorcycle or ATV Clamp Adapter — Secures
wheel to table top for tire changing.
9 Lube Bottle — Dispenser for rubber lubricant.
10 DuckHead ® (Combination Mount/Demount Tool)
— Mounts and demounts tire from wheel.
11 Swing Arm Adjustment Knob — Adjusts swing
arm/vertical slide assembly for proper horizontal posi-
tioning of mount/demount tool.
12 Vertical Slide Locking Handle — Locks and
unlocks vertical slide and sets correct vertical position
to maintain tool/wheel clearance.
13 Bead Lifting Tool — Used to lift and position tire
bead correctly on Duckhead mount/demount tool.
14 Bead Loosener Shoe — Pivoting shoe for loosen-
ing tire beads.
15 Oil Check Dipstick — For transmission oil level.
16 ATV Riser Plate — Adjusts to raise ATV wheels to
centerline of bead loosener.
17 Pressure Safety Valve — The high pressure safety
valve is set to exhaust at line pressures above 185 PSI.
18 Release Valve — Allows the manual release of air
pressure from tire when clip-on chuck is attached to tire
valve.
