COATS 550 Heavy Duty Tire Lift User Manual
550 heavy duty tire lift, For use with coats heavy duty wheel balancers
550 Heavy Duty Tire Lift
For use with COATS Heavy Duty Wheel Balancers
READ these instructions before placing unit in
service. KEEP these and other materials delivered
with the unit in a binder near the machine for ease
of reference by supervisors and operators.
Safety Instructions
Installation Instructions
Operating Instructions
Maintenance Instructions
with Parts Identification
1601 J. P. Hennessy Drive, LaVergne, TN USA 37086-3565 615/641-7533 800/688/6359 www.ammcoats.com
Manual Part No.: 85607341 01
HENNESSY INDUSTRIES INC. Manufacturer of AMMCO
®
, COATS
®
and BADA
®
Automotive Service Equipment and Tools.
Revision:
12/11
