Copyright © 2010 CiDRA Corporate Services

Page B-5

20958-01 Rev 02

Opening the device will launch SIMATIC PDM which will then allow
modifying and displaying all the variables available in the transmitter.

Figure 20

Transmitter Variables

Update the information by clicking on ‘Upload to PG/PC’. Data will be
read from the transmitter. The ‘PA’ LED will flicker on the DP/PA
coupler.
