Table 3 Transducer Block Configurations
Parameter / Structure Name Data Type Access Help
CONTROL
WRITE_CONTROL Unsigned16 R/W
Controls ability to write and commit changes to
transmitter configuration.
RESET_TOTALIZER Unsigned16 R/W Resets all totalizers to zero.
CLEAR_ALARM Unsigned16 R/W Clear any existing alarms.
CLEAR_DATA_HISTORY Unsigned16 R/W Clears the data history memory.
DEVICE_INFO
PSN_TRANSMITTER_S/N Octet String R Transmitter Serial Number
PSN_MODEL_NUMBER Octet String R Transmitter Model Number
PSN_SOFTWARE_REVISION Octet String R Transmitter Software Revision
PSN_ALCHEMY_SOFTWARE_REVISION Octet String R Alchemy Software Revision
PSN_SENSORHEAD_S/N Octet String R Sensor head Serial Number
PSN_PREAMP_SOFTWARE_REVISION Octet String R Preamp Software Revision
PSN_PREAMP_SERIAL_NUMBER Octet String R Preamp Serial Number
PIPE_INFORMATION
PIPE_DIAMETER_INPUT_MODE
Unsigned
Char
R/W
Selects method used to set pipe dimensions.
PIPE_DIAMETER_UNITS
Unsigned
Char
R/W
Selects units used for 'Pipe ID'.
PIPE_ID Float R/W
Pipe Inside Diameter Measurement. Will only be
applied if 'Inside Diameter' is selected for 'Pipe
Diameter Input Mode'.
PIPE_OD Float R/W
Pipe Outside Diameter Measurement. Will only be
applied if 'Outside Diameter / Wall Thickness' is
selected for 'Pipe Diameter Input Mode'.
PIPE_OD_WALL_UNITS
Unsigned
Char
R/W
Selects units used for 'Pipe OD' and 'Pipe Wall
Thickness'. Will only be applied if 'Outside Diameter /
Wall Thickness' is selected for 'Pipe Diameter Input
Mode'.
