Table 3 Transducer Block Configurations (Page 18)
SENSOR_3_MIN Long R Sensor 3 minimum in A/D bins.
SENSOR_4_MIN Long R Sensor 4 minimum in A/D bins.
SENSOR_5_MIN Long R Sensor 5 minimum in A/D bins.
SENSOR_6_MIN Long R Sensor 6 minimum in A/D bins.
SENSOR_7_MIN Long R Sensor 7 minimum in A/D bins.
SENSOR_8_MIN Long R Sensor 8 minimum in A/D bins.
SENSOR_ALPHA
SENSOR_ALPHA_1 Float R
Relative scale factor between signal magnitudes
acquired from each sensor.
SENSOR_ALPHA_2 Float R
Relative scale factor between signal magnitudes
acquired from each sensor.
SENSOR_ALPHA_3 Float R
Relative scale factor between signal magnitudes
acquired from each sensor.
SENSOR_ALPHA_4 Float R
Relative scale factor between signal magnitudes
acquired from each sensor.
SENSOR_ALPHA_5 Float R
Relative scale factor between signal magnitudes
acquired from each sensor.
SENSOR_ALPHA_6 Float R
Relative scale factor between signal magnitudes
acquired from each sensor.
SENSOR_ALPHA_7 Float R
Relative scale factor between signal magnitudes
acquired from each sensor.
SENSOR_ALPHA_8 Float R
Relative scale factor between signal magnitudes
acquired from each sensor.
FIELDBUS_INFO
FIRMWARE_REVISION Octet String R Softing FBK firmware revision
PD_TAG Octet String R Fieldbus Physical Device Tag
DEVICE_ID Octet String R Fieldbus device ID
NODE_ADDRESS
Unsigned
Char
R
Fieldbus node address
BLOCK_MODE_RB
Unsigned
Char
R
Resource Block Mode
BLOCK_MODE_TB
Unsigned
Char
R
Transducer Block Mode
