Using SIMATIC Manager / PDM
Note: This document is not intended as a tutorial on SIMATIC;
reference the Siemens manual for that program.
Tools provided by Siemens allow a user to import ‘EDDL’ (Enhanced
Device Description Language) files to the SIMATIC program to define
how a device will appear.
The user must run ‘Manage Device Catalog…’. This allows the user
to import the required files, and only need to be done once.
Figure 17
Using SIMATIC Manager / PDM
