CiDRA Use of Foundation Fieldbus Protocol with SONARtrac Transmitters - Manual (Page 19)

Table 3 Transducer Block Configurations (Page 6)
SPL_STD_DEV Float R
The standard deviation of the SPL measurements from
all active sensors.
PREAMP
PREAMP_GAIN
Unsigned
Char
R/W
Gain selection for the preamp. Set a value 0 thru 3 to
choose gain listed by 'Preamp Gain 0'* 'Preamp Gain 1'*
'Preamp Gain 2' or 'Preamp Gain 3'
PREAMP_AUTO_GAIN_MODE
Unsigned
Long
R/W
Preamp Auto Gain Mode
PREAMP_CHARGE_GAIN Float R Charge gain as read from the preamp.
PREAMP_GAIN_0 Float R Preamp Gain 0 as read from the preamp.
PREAMP_GAIN_1 Float R Preamp Gain 1 as read from the preamp.
PREAMP_GAIN_2 Float R Preamp Gain 2 as read from the preamp.
PREAMP_GAIN_3 Float R Preamp Gain 3 as read from the preamp.
FLOW_ALGORITHM
FLOW_SAMPLE_FREQ Float R/W
Set A/D sample frequency in samples per second.
Enter one of the following: 3906.25* 2055.921.
FLOW_CHANNEL_SKEW Float R/W Flow Channel Skew
FLOW_FREQ_MIN Float R/W
Set minimum frequency for k-w processing. Normally
set by DSP. User modified if using single or fixed
modes or auto mode with VF_OP_MODE_SETTINGS
set to 1 (FIXED_FREQUENCY). Go to Idle mode* then
set this parameter* then select single/fixed.
FLOW_FREQ_MAX Float R/W
Set maximum frequency for k-w processing. Normally
set by DSP. User modified if using single or fixed
modes or auto mode with VF_OP_MODE_SETTINGS
set to 1 (FIXED_FREQUENCY). Go to Idle mode* then
set this parameter* then select single/fixed.
FLOW_RATE_MIN Float R/W
Minimum valid flow rate reading in configured display
units.
FLOW_RATE_MAX Float R/W
Maximum valid flow rate reading in configured display
units.
FLOW_MIN_QUALITY Float R/W Minimum quality threshold for VF display and output.
Copyright © 2010 CiDRA Corporate Services Page 5-7
20958-01 Rev 02
