Table 3 Transducer Block Configurations (Page 17)

TEMPERATURE Float

R

Temperature as used in calculation of GVF in
configured units.

SOS_QUALITY Float

R

Measured SOS quality.

SOS_UNFILTERED Float

R

Measured SOS in ft/s without any filtering applied.

SOS_FLOW_RATE Float

R

Measured SOS flow rate.

SOS_FLOW_QUAL Float

R

Measured SOS flow quality.

TLF Float

R

Measured True Liquid Flow in configured flow units.

TOTAL_TLF Float

R

Measured total TLF.

TLF_UNFILTERED Float

R

Measured TLF in ft/s without any filtering applied.

ANALOG_4_20MA_INPUT_1 Float

R

Measured analog input 1 in mA.

ANALOG_4_20MA_INPUT_2 Float

R

Measured analog input 2 in mA.

TOTAL_FLOW_FRACTION Float

R

Floating point fraction to be added to 'Total Flow Carry' *
100 to calculate full resolution total flow.

TOTAL_TLF_FRACTION Float

R

Floating point fraction to be added to 'Total TLF Carry' *
100 to calculate full resolution total TLF.

TOTAL_FLOW_CARRY

Unsigned
Long

R

Signed long portion (* 100) to be added to 'Total Flow
Fraction' to calculate full resolution total flow.

TOTAL_TLF_CARRY

Unsigned
Long

R

Signed long portion (* 100) to be added to 'Total TLF
Fraction' to calculate full resolution total TLF.

SYSTEM_STATUS

Unsigned
Long

R

Refer to manual for description of individual bits.

SENSOR_MAX_MIN

SENSOR_1_MAX Long

R

Sensor 1 maximum in A/D bins.

SENSOR_2_MAX Long

R

Sensor 2 maximum in A/D bins.

SENSOR_3_MAX Long

R

Sensor 3 maximum in A/D bins.

SENSOR_4_MAX Long

R

Sensor 4 maximum in A/D bins.

SENSOR_5_MAX Long

R

Sensor 5 maximum in A/D bins.

SENSOR_6_MAX Long

R

Sensor 6 maximum in A/D bins.

SENSOR_7_MAX Long

R

Sensor 7 maximum in A/D bins.

SENSOR_8_MAX Long

R

Sensor 8 maximum in A/D bins.

SENSOR_1_MIN Long

R

Sensor 1 minimum in A/D bins.

SENSOR_2_MIN Long

R

Sensor 2 minimum in A/D bins.
