System Map: Front & Left Views 1 - 17

Quick Start Guide

1

System Map: Front & Left Views

Figure 1 - 9

Front & Left Views

1.

LED Indicators

2.

DC-In Jack

3.

External Monitor
Port

4.

RJ-45 LAN Jack

5.

Vent/Fan Intake/
Outlet

6.

HDMI-Out Port

7.

2 * USB 2.0 Ports

8.

ExpressCard Slot
(see page

2 - 7

)

9.

7-in-1 Card Reader

1

2

5

4

1

6

3

7-in-1 Card Reader

The card reader allows you to use the most popular digital storage card formats:

MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /

MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter) /

Mini SD (requires PC adapter) / RS MMC (requires PC adapter)

8

7

7

9
