Modules & Options
7 - 32 3.75G/HSPA Module
7
• For Model C
8. Insert the USIM card as you would into your mobile phone.
9. Slide the SIMLOCK towards the hinge in order to release the lock and lift it up.
10. Insert the USIM card as illustrated in ( Figure 7 - 26 ) and close the SIMLOCK.
11. Lock the SIMLOCK by pushing it in the direction of the arrow in Figure 7 - 27 until
it clicks into the lock position.
Figure 7 - 26
Insert the USIM
Card
3.75G/HSPA
Modules & System
Wake Up
Note that the 3.75G
modules DO NOT sup-
port system wake up on
3.75G/HSPA modem
activity.
Figure 7 - 27
SIMLOCK Lock
