chiliGREEN M770K - Manual (Page 151)

Modules & Options
3.75G/HSPA Module 7 - 29
7
1. Turn off the computer, and turn it over and remove the battery.
2. Access the SIMLOCK as follows:
• For Models A & B: Locate the RAM & CPU bay cover and remove screws -
(the SIMLOCK is located at point ), then carefully (a fan and cable are
attached to the under side of the cover) lift up the bay cover. Carefully discon-
nect the fan cable
, and remove the cover.
• For Model C: Locate the SIM card cover and loosen screw , and then remove
the SIM card cover .
Power Safety
Warning
Before you undertake
any installation proce-
dures, make sure that
you have turned off the
power, and disconnect-
ed all peripherals and
cables (including tele-
phone lines). It is advis-
able to also remove your
battery in order to pre-
vent accidentally turning
the machine on.
Figure 7 - 22
SIM Card Cover/Bay
Cover Removal
1
3 4
5
6
7
1
2 3 1
2
Model A
Model B
4 4
3
5 5
7
6
Model C
