BIOS Utilities
5 - 8 Advanced Menu
5
Advanced Menu
SATA Mode (Advanced Menu)
You may enable/disable SATA RAID or AHCI mode for your hard disks, however
you should only enable/disable SATA RAID or AHCI BEFORE installing an
operating system, and after you have backed up all necessary files and data (see
sidebar).
Figure 5 - 3
Advanced Menu
Main A Advanced Security Boot Exit
F1 Help Select Item - / + Change Values F9 Setup Defaults
Esc Exit Select Menu Enter Select Sub-Menu F10 Save and Exit
Item Specific Help
Advanced
Phoenix SecureCore(tm) Setup Utility
SATA Mode [ AHCI ]
Legacy USB Support: [Enabled]
Boot-time Diagnostic Screen: [Disabled]
Power On Boot Beep [Disabled]
Battery Low Alarm Beep: [Disabled]
Determines how SATA
controller(s) operate.
SATA Mode
If you have installed the
Windows 7 operating
system with either AHCI
or RAID mode enabled,
DO NOT disable the set
mode (if you wish to dis-
able the set mode you
will need to reinstall the
Windows 7 OS).
