35
Detergent tank Assembly
I tem Qty. Part Description
No. No.
17 4 0507431 Bolt M6 x 25mm (metric)
18 1 107886 Inlet Chute Gasket
19 4 107435 Nut, M6 (metric)
20 1 0512535 Molded Drain Seat
21 1 0512536 Drain Gasket
22 1 0512534 Modeled Drain Tee
23 2 0502571 Hose Clamp 1-1/2"
24 1 0512533 Molded Drain Hose
25 1 0512550 Float Rod Bushing
26 1 201669 1/4" NPS NP Brass Nut
27 1 0501600 Stem Thermometer 8"
28 1 0501896 Thermometer Seal
29 1 0501836 O-ring
30 1 0507323 Thermostat
31 1 0501650 Thermostat Adapter
32 1 0507315 Detergent Tank Heater 3kW
33 1 0700948 Detergent Tank Standpipe
34 1 0507471 Label (CLEAN SCREENS DAILY)
1 1 0312592 Steam Cover
2 1 0312591 Detergent Tank Cover
3 1 0712641 Detergent Tank Screen
4 1 0501395 Set Screw 1/4-20
5 1 0312682 Float Cam
6 1 0501397 Set Screw 6-40
7 1 0703673 Cam Bushing (set screw included)
8 1 0512554 Float Rod
9 1 0503670 Float Ball
10 1 0712640 Detergent Tank
11 1 0307427 Water Inlet Tube
12 1 0503679 Hose Clamp #6
13 A/R 0502665 Braided Hose 1/2"
14 6" 0502668 PVC Hose 1" ID x 1-3/8" OD
15 1 0502563 Gear Clamp 1"
16 1 108051 Elbow Flange
