CHAMPION CG Manual User Manual
Page 39
31
Inlet Plumbing
Item
No.
Part
No.
Description
Qty.
1
0502783
Solenoid Valve, 230VAC/60 HZ
2
2
0502802
3/8” MPT Tee
3
3
0503801
3/8” Fem x 1/2” Adapter
1
4
0507324
3/8” Check Valve
1
5
0502768
Mixing Valve
1
6
0502653
3/8” x 1/2’ 90º Hose Barb
2
7
0503679
7/16” Gear Clamp
2
8
0502665
1/2” I.D. Braided Hose
AR
9
0509659
Brass Cap
1
10
0504822
Screw 8-32 x 1/2”
2
11
0306208
Cable Clamp Cover
2
12
0307373
Cable Clamp Assy.
2
13
0501404
Screw 10-32 x 3/8” Brass
2
14
0501493
Lock Washer #10
2
15
0501533
Nut 10-32 Brass
2
16
0505229
Solenoid Guide
1
17
0502811
Diaphragm Kit
AR
18
0502810
Flow Washer (2.6 gpm)
1
19
0502807
Brass Washer
1
20
0502804
Brass Washer
1
21
0502803
Screen
1
22
0501406
Screw 8-32 x 1/2”
2
23
0502806
Coil, Solenoid Valve, 230VAC/60
1
