21
Wash Hubs, Spray Arms
I tem Qty. Part Description
No. No.
*1 2 0501613 Wash Arm
*2 2 0501738 Rinse Arm
3 4 0501608 O-ring
4 1 0501610 Top Manifold
5 1 0301622 Bottom Manifold
6 1 106026 Flat Washer, 1/4"
7 2 0501422 Bolt, 1/4-20 x 1-1/2"
8 2 0501412 Screw, 10-32 x 3/8"
9 2 0500813 Bottom Manifold Inlet Tube
10 AR 0502663 Braided Hose, 3/8"
11 4 0303679 Gear Clamp #6
12 2 0509478 Grommet
13 1 0300908 3/8" SST Tube
Note:
* Wash and rinse spray arms have notches to make sure they are installed correctly.
