3. Configuring the WLA-9000AP
15
AirLive WLA-9000AP User’s Manual
SSH2 provide the possibility to write a text script and paste into the CLI interface for
multiple command execution. It also makes configuration change across many
WLA-9000APs easier. The default management port for SSH/SSH2 is TCP/UDP
port 22.
To manage via the SSH/SSH2 protocol, you would need a SSH client. Free SSH
clients are widely available on the Internet. You can find where to download them
by using Internet search engine such as Google. In this guide, we will use a
popular SSH/Telnet utility call Putty.
Once you have download and install Putty. Please follow the figure below to make
a connection with WLA-9000AP:
1.
Choose “SSH” as indicated in the diagram
2.
Enter the IP address of WLA-9000AP
3.
Click on “Open” to start the SSH session.
When the following screen appear, click on “Yes” to continue
1
2
