4. Wireless and WAN Settings
AirLive AirMax DUO Lite User’s Manual
80
Step 1
From Operation Mode menu, select “Setup” -> “Bandwidth Control”
Step 2 ~ 5
Enable the Bandwidth Control and select the “Total Bandwidth Control”. Then enter the
“2048” for Total Downlink Speed and “512”kbps for Total Uplink Speed. Click “Apply” to
finish
Example 2: Per User Bandwidth Control
In this example, the AirMax DUO Lite is Access Point mode. There is a wireless client
connecting to AirMax DUO Lite with MAC address of 00:04:6F:11:11:11. We want to limit
the bandwidth of the wireless client to 1024 downstream and 512K upstream using AirMax
DUO Lite’s Per-User Bandwidth Control.
2
3
5
4
