4. Wireless and WAN Settings
49
AirLive AirMax DUO Lite User’s Manual
4.2 General Wireless Settings
The wireless settings of AirMax DUO Lite are dependant on the wireless operation mode
you choose. Therefore, the first step is to choose the operation mode. For explanation on
when to use what operation mode, please refer to Chapter 1.
When you select “Wireless Settings” in the welcome screen, or click on the “Operation
Mode” on the top menu; the following screen will appear:
Mode: The available wireless operation modes for AirMax DUO Lite. Select one and
click on “Change Mode” button to switch between modes.
This tells your
current operation
mode now
Select one of the
wireless operation
modes here
Configure Wireless and WAN
settings
After you select the
new operation
mode, click here to
change.
