4. Wireless and WAN Settings
AirLive AirMax DUO Lite User’s Manual
78
You must select between Total Bandwidth and Per-User Bandwidth. They can not be
enabled at the same time.
Total Bandwidth: Total Bandwidth control limit the bandwidth between
Wireless and Ethernet interface. Therefore, it is most suitable for Client
Infrastructure Mode, Bridge Mode, and WISP Router Mode. For WISP
operator who use AirMax DUO Lite as the client side device; setting the Total
Bandwidth control on the AirMax DUO Lite will easy the loading on the AP for
bandwidth management. To begin, please enable the Bandwidth
Management first. Then enter the downlink and uplink speed; click on Apply
to finish.
Total Downlink Speed: Enter speed you wish to limit the download traffic
in Kbps units.
Total Uplink Speed: Enter the speed you wish to limit the upload traffic in
Kbps units.
Per User Bandwidth Control: Per user Bandwidth Control can limit speed of individual PC
and network device. The AirMax DUO Lite allows multiple Per-User bandwidth rules and
can limit the bandwidth by IP address, MAC address, or IP segment. Please first enable the
Bandwidth Control, then select “Per User Bandwidth Control” to begin. It is recommended
to use this type of bandwidth control for Access Point and AP Router mode.
Per User Control Options
Description: Enter a description for the bandwidth policy. For example,
“VIP” subscriber
Type: AirMax DUO Lite offers 3 types of Per-User Control
IP Address: To limit the bandwidth of one single IP address.
IP Segment: To limit the bandwidth the entire IP segment.
For example; if you enter the address of 192.168.1.20 with subnet mask of
255.255.255.248, the AirMax DUO Lite will limit bandwidth of IP addresses from
192.168.1.17 to 192.168.1.22. Please use an online IP calculate if you are not familiar with
IP segment calculation. Below is an example link:
http://www.subnet-calculator.com/
