5. System Configuration

AirLive AirMax DUO Lite User’s Manual

136

5.1.11 AirMax DUO Lite Emergency Recovery

This section guides to recover your AirMax DUO Lite system if the firmware crashed.

1. Download the tftp server to your PC. In the following example, we use tftpd32:

http://tftpd32.jounin.net/tftpd32_download.html.

2. Copy the tftpd32.exe of the downloaded file to C:\.
3. Change the IP address of your PC to 192.168.1.254 / 255.255.255.0
4. Copy the AirMax DUO Lite firmware to C:\ and rename the firmware to “zImage”.

Note that the name must be zImage and no extension.

5. Connect AirMax DUO Lite and PC with an Ethernet cable.
6. Run the tftpd32.exe. Note that the IP address must be 192.168.1.254.
