1. Introduction
AirLive AirMax DUO Lite User’s Manual 2
Multiple Operation Modes
The AirMax DUO Lite can operate in multiple wireless modes for different application
environments such as Dual AP, Dual WDS, Duplex link aggregation, Separate Bridge, AP +
Client, AP + WDS, WDS + Gateway, AP + Gateway, and AP + WISP. These modes can be
changed and configured easily by the Web user interface.
802.3af PoE Port
AirMax DUO Lite is equipped with an 802.3af Power over Ethernet port. It thus can be
powered by a PoE PSE and operate at up to 100 meter away.
VLAN & QoS
AirMax DUO Lite provides Multi-SSID to create different wireless networks using one AP.
The TAG VLAN feature allows service provider to control service content of each SSID
network all the way back to core router. The QoS feature allows prioritizing the different
package according the 802.11e WMM protocol and triple play (Voice, Video and Data).
Bandwidth control feature allow AirMax DUO Lite to limit the bandwidth on distinct IP/MAC
or on the total device.
IP65 Environmental Protection Enclosure
With IP-65 standard enclosure, AirMax DUO Lite is highly protected against dust and water.
So that AirMax DUO Lite can be used in a hardened environment.
