4. Wireless and WAN Settings
71 AirLive AirMax DUO Lite User’s Manual
VLAN IP: Each SSID can be given with different VLAN IP group. Please notice that the
management IP in the VLAN will also be changed. For example, if you define the
VLAN IP to be 192.168.2.X subnet, then the AirMax DUO Lite’s management IP in the
group will change to 192.168.2.1.
VLAN IP NetMask: Define your VLAN IP scope here
802.1p Priority: Define your 802.1p priority Tag here. Value from 0 to 7
Select DSCP TYPE: Assign the 6-digit DifferServ Code (DSCP) for the packets in the
SSID network for QoS purpose. There are 8 preset values. To assign your own value,
please select “Best Effort”
DSCP Value: When you select “Best Effort” DSCP Type, you can enter the 6-dgit
DSCP Value here.
Select Security Policy: Select the encryption used for this SSID VLAN group. This
policy can be different in each SSID VLAN group. For example, one SSID can be using
WEP; the other policy can use WPA-PSK.
Once you enable the VLAN ID. The incoming packet from Ethernet
port to your VLAN group must carry the same VLAN ID tag or the
packet will be dropped.
4.2.13 WMM QoS Setting
Operation Mode -> Setup -> WMM QoS Setting
Wi-Fi Multimedia (WMM) is a standard to prioritize traffic for multimedia applications. The
WMM Settings is to specify parameters on multiple data queue for better performance of
differentiated wireless traffic like Voice-over-IP (VoIP), other types of audio, video, and
streaming media as well as traditional IP data over the AP.
