4. Wireless and WAN Settings
85
AirLive AirMax DUO User’s Manual
When you click on WDS settings, the following screen will appear:
WEP Key: You can set up to 4 keys; each key can have different Key Length and Key type.
When you add an entry to the WDS setting and select WEP encryption, the system will ask
you which key to use. All devices on the network must have the same sets of keys, but each
link can have use different key. We recommend using WEP-152 whenever possible for
better security.
Adding a new WDS link
The WDS links are created by entering the remote Bridge’s information. This process must
be repeated on both side of the bridge.
This is where you
enter the remote
Bridge’s information.
The SSID must be
different between
each Bridge.
Here are the
encryption key
settings for
WEP. Please
make sure all
bridges in the
WDS network
enter the same
keys.
After you add
a remote
Bridge, it will
be display
here. Up to 4
entries are
possible
