4. Wireless and WAN Settings
75 AirLive AirMax DUO User’s Manual
Shared Secret: This is used by your RADIUS server in the Shared Secret
field in RADIUS protocol messages. The shared secret configured in the
AIRMAX DUO must match the shared secret configured in the RADIUS
server. The shared secret can contain up to 64 alphanumeric characters.
RADIUS Server Reattempt Period: The number of times the AIRMAX DUO
should attempt to contact the primary server before giving up
4.2.15 Bandwidth Control
Operation Mode -> Setup -> Bandwidth Control
Bandwidth Control can limit the maximum speed of entire wireless interface or individual
device. It is also known as Traffic Shaping. The AirMax DUO provides both Total Bandwidth
and Per-User Bandwidth Control for both uplink and downlink speed. It controls the speed
of both wireless and wired interface.
To configure, please click on the “Bandwidth Control” button under wireless settings. The
following screen will appear:
