4. Wireless and WAN Settings
49 AirLive AirMax DUO User’s Manual
4.2.1 Regulatory Domain
Operation Mode -> Setup -> Regulatory Domain
The legal frequency and channels in 5GHz spectrum varies between countries. Please
select your country from here. There is a special domain called “Test Domain” which will
show all the channels. It is for compatibility testing only. Please make sure the channel you
used is allowed in your country when select this special domain.
4.2.2 Network SSID
Operation Mode -> Setup -> Network SSID
The SSID is the network name used to identify a wireless network. The SSID must be the
same for all devices in the same wireless network. In AirMax DUO, it is possible to create
more than one SSID in AP and AP Router mode, please check the “Multiple SSID & VLAN”
section in this chapter. Conversely, several access points on a network can have the same
SSID. The SSID length is up to 32 characters. The default SSID is “airlive”.
Enable Radio 1/2: The default wireless is on. You can uncheck this box to disable
wireless interface.
Disable SSID Broadcasting: If you check this box, the SSID will be hidden; only users
who know the SSID can associate with this network.
4.2.3 Site Survey
Operation Mode -> Setup -> Site Survey
The Site Survey function in AirMax DUO provides 4 important functions
In Client and Bridge Infrastructure mode, site survey will scan for available AP
network. Then allow user to select and connect to the AP. These greatly
simplify the installation.
Once Site Survey displays the available AP or Bridge networks, you can
select a particular SSID to display its RSSI value continuously. This function is
called “Signal Survey”. Signal Survey can be used for antenna alignment.
