4. Wireless and WAN Settings

AirLive AirMax DUO User’s Manual

VLAN ID: Packets going out of this VLAN will be tagged with the VLAN ID Packets
coming into the AP will be dropped if the VLAN Tag does not match. The valid range is

between 0 to 4095. The VLAN ID “0” is the default VLAN group.

VLAN IP: Each SSID can be given with different VLAN IP group. Please notice that the
management IP in the VLAN will also be changed. For example, if you define the

VLAN IP to be 192.168.2.X subnet, then the AirMax DUO’s management IP in the
group will change to 192.168.2.1.

VLAN IP NetMask: Define your VLAN IP scope here

802.1p Priority: Define your 802.1p priority Tag here. Value from 0 to 7

Select DSCP TYPE: Assign the 6-digit DifferServ Code (DSCP) for the packets in the
SSID network for QoS purpose. There are 8 preset values. To assign your own value,

please select “Best Effort”

DSCP Value: When you select “Best Effort” DSCP Type, you can enter the 6-dgit
DSCP Value here.

Select Security Policy: Select the encryption used for this SSID VLAN group. This
policy can be different in each SSID VLAN group. For example, one SSID can be using

WEP; the other policy can use WPA-PSK.

Once you enable the VLAN ID. The incoming packet from Ethernet
port to your VLAN group must carry the same VLAN ID tag or the
packet will be dropped.
