SECTION 2 - GROUND COMPONENTS
3121682 2032ES/2632ES 87
FIGURE 2-17. BATTERIES INSTALLATION - EV TYPE - 244 AH RATING (NON-UL LOCKING COVERS)
ITEM PART NUMBER QTY DESCRIPTION REV
0275044 Ref BATTERIES INSTALLATION - EV TYPE - 244 AH RATING (NON-
UL LOCKING COVERS) C
1 0273698 2 Tray Assembly (See BATTERY TRAY ASSEMBLY - NON UL for
Breakdown)
2 0400216 4 Battery Type EV-145-WNL
3 0760610 8 Bolt M6 x 20
4 1671204 2 Cover Assembly (See BATTERY COVER ASSEMBLY - LOCKING
for Breakdown)
5 3290605 2 Nut M6
6 3574981 2 Plate, Slide Stop (LH)
7 3574984 2 Plate, Slide Stop (RH)
8 4031713 2 Capscrew M6 x 45
9 4191707 8 Screw M6 x 16
10 4811700 8 Washer M6
11 0100051 AR Grease, Terminal
12 1001112113 1 Sensor, Temperature
