Page 29
SECTION 1 - FRAME
3121682
2032ES/2632ES
29
FIGURE 1-8. PROTECTION INSTALLATION - UL
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001178357
Ref
POTHOLE PROTECTION INSTALLATION - UL
B
1
0700614
4
Bolt M6 X 30
2
3010158
2
Link
3
3290405
4
Nut M4
4
3290605
4
Nut M6
5
3291005
4
Nut M10
6
3423045
4
Pin, Pivot
7
3423189
4
Pin, Pivot
8
3423267
2
Pin
9
3574176
2
Plate, Link
10
3760348
16
Ring, Retaining
11
5272012
4
Capscrew M10 X 40
12
4031512
4
Capscrew M4 X 40
13
4740086
4
Washer, Thrust
14
4811700
4
Washer M6
15
4812000
4
Washer M10
16
4846816
1
Support (RH)
17
4846863
1
Support (LH)
18
1001109232
1
Plate, Mounting
19
1001109233
1
Plate, Mounting
20
1001126905
2
Switch, Limit
20
4460535
2
Receptacle, Female - 4 Position (1 per Switch)
20
4460464
8
Pin, Male (4 per Switch)
21
1001178239
1
Actuator Assembly (Includes Items 21A-21E)
B
21A
3760115
1
Ring, Retaining
21B
4160202
1
Spring
21C
1001178146
1
Pad
21D
1001178147
1
Plate
21E
0060091
1
Bracket, Actuator
