SECTION 5 - CYLINDER
182 2032ES/2632ES 3121682
FIGURE 5-2. LIFT CYLINDER ASSEMBLY - 2032ES WITH STANDARD HYDRAULIC OIL (CHINA BUILT
MACHINES)
ITEM PART NUMBER QTY DESCRIPTION REV
1001129289 Ref LIFT CYLINDER ASSEMBLY - 2032ES WITH STANDARD
HYDRAULIC OIL (CHINA BUILT MACHINES) E
1 70004628 1 Barrel
2 70004629 1 Rod
3 70004630 1 Head, Cylinder
4 See Note NSS Seal, Dust (Note: Use Item 20)
5 See Note NSS Seal (Note: Use Item 20)
6 70004631 1 Bearing
7 See Note NSS O-Ring (Note: Use Item 20)
8 See Note NSS O-Ring (Note: Use Item 20)
9 70004632 1 Piston
10 See Note NSS Seal (Note: Use Item 20)
11 See Note NSS Ring, Wear (Note: Use Item 20)
12 See Note NSS O-Ring (Note: Use Item 20)
13 70003663 1 Nut
14 0962257 4 Bushing
15 70004943 1 Motor/Pump/Tank Assembly (See Items 102-138 for Breakdown)
16 See Note 1 O-Ring (Note: Use Item 20)
17 70004624 2 Capscrew M10 x 40
18 70004625 3 Capscrew M8 x 20
19 70004626 2 Plug, Extension
20 70004633 1 Seal Kit - Cylinder (Includes Items 4,5,7,8,10,11,12&16)
70004943 Ref MOTOR/PUMP/TANK ASSEMBLY
102 70004914 1 O-Ring
103 70004915 1 Cartridge, Valve (Main Relief)
104 70004916 1 Cartridge, Valve (Breather Vacuum Check)
105 70004917 1 Cartridge, Valve (Breather Pressure Check)
106 2220883 6 Plug
107 70004918 2 Pin, Dowel
108 See Note NSS Motor (Note: Not Available - Purchase Complete Assembly)
109 See Note 1 Adapter Assembly (Includes Adapter Plate, Coupling and
Attaching Hardware (Note: Not Available - Purchase Complete
Assembly)
110 70003693 1 Pump (Note: No Serviceable Parts Available - Purchase Complete
Pump)
111 70003694 2 Washer M8
112 70004919 2 Capscrew M8 x 60
113 70004940 1 Tank
114 70004921 2 Plug
115 70004922 4 Bolt M6 x 12
116 70004923 4 Capscrew M10 x 140
117 70004924 4 Washer M10
118 70004925 2 O-Ring
119 70003028 1 Cartridge, Solenoid Valve Less Coil (Steer)
120 70004926 1 Cartridge, Solenoid Valve Less Coil (Lift)
121 See Note 1 Cartridge, Solenoid Valve (Platform Lowering) (Note: Cartridge
and Coil Not Available at Time of Printing)
122 70004927 2 Cartridge, Valve (Steer Relief)
123 70004585 1 Cartridge, Valve (Lift Check)
124 70004928 1 Filter 300 micron
