SECTION 3 - SCISSORS ARMS
3121682
2032ES/2632ES
127
FIGURE 3-9. SCISSORS ARMS INSTALLATION - 2632ES STANDARD HYDRAULIC OIL (USA BUILT
MACHINES)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001157323
Ref
SCISSORS ARMS INSTALLATION - 2632ES STANDARD
HYDRAULIC OIL (USA BUILT MACHINES)
A
1
1001157317
1
Arms Assembly (See SCISSORS ARMS ASSEMBLY - 2632ES
STANDARD HYDRAULIC OIL (USA BUILT MACHINES) for
Breakdown)
2
0701022
1
Bolt M10 x 70
3
1061034
1
Cable, Manual Descent
3
7020218
1
T-Handle (with 1/4-20 Threads)
3
70001878
1
T-Handle (with M5 Threads)
5
3200454
1
Mount, Switch
6
3291005
1
Nut M10
8
3321402
1
Nut 1/4-28
9
3340957
2
Pad, Slide
10
3423259
1
Pin, Sensor
12
4160078
1
Spring, Compression
13
4191706
3
Screw M6 x 12
16
1001092354
1
Switch, Rotary Angle Sensor
16
4460536
1
Receptacle, Female - 3 Position
16
4460464
3
Pin, Male
100
0440265
1
Bushing (Part of Frame Weldment)
