SECTION 7 - ELECTRICAL
3121682 2032ES/2632ES 227
FIGURE 7-6. AC BOX AT PLATFORM INSTALLATION-220V CEE7 SIDE GRD (CE SPEC ONLY)
ITEM PART NUMBER QTY DESCRIPTION REV
1001162447 Ref AC BOX AT PLATFORM INSTALLATION - 220V CEE7 SIDE
GRD(CE SPEC ONLY) A
1 0275453 1 Receptacle Box Kit - 220V CEE7 Side Ground (See
RECEPTACLE BOX KIT - 220V CEE7 SIDE GROUND for
Breakdown)
2 3252507 1 Decal - 220V - 50/60Hz
3 3290405 4 Nut M4
4 4010408 4 Screw M4 X 16
5 4010608 2 Screw M6 x 16
6 4191707 4 Screw M6 x 16
7 4460662 1 Connector, Strain Relief
8 4811700 10 Washer M6
9 1001091102 8 Washer M4
10 1001152485 1 Breaker Box Kit (See BREAKER BOX KIT WITH THREE
BREAKERS - CE SPEC ONLY for Breakdown)
11 1001162362 1 Bracket
