SECTION 3 - SCISSORS ARMS
3121682
2032ES/2632ES
145
FIGURE 3-15. SCISSORS ARMS INSTALLATION - 2632ES BIODEGRADEABLE HYDRAULIC OIL
(CHINA BUILT MACHINES)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001131011
Ref
SCISSORS ARMS INSTALLATION - 2632ES BIODEGRADEABLE
HYDRAULIC OIL (CHINA BUILT MACHINES)
C
1
1001131029
1
Arms Assembly (See SCISSORS ARMS ASSEMBLY - 2632ES
BIODEGRADEABLE HYDRAULIC OIL for Breakdown)
2
0701022
1
Bolt M10 x 70
3
1061034
1
Cable, Manual Descent
3
7020218
1
T-Handle (with 1/4-20 Threads)
3
70001878
1
T-Handle (with M5 Threads)
4
3200454
1
Mount, Switch
5
3291005
1
Nut M10
6
3321402
1
Nut 1/4-28
7
3340957
2
Pad, Slide
8
3423259
1
Pin, Sensor
9
4160078
1
Spring, Compression
10
4191706
3
Screw M6 x 12
11
1001092354
1
Switch, Rotary Angle Sensor
11
4460536
1
Receptacle, Female - 3 Position
11
4460464
3
Pin, Male
100
0440265
1
Bushing (Part of Frame Weldment)
