SECTION 4 - PLATFORM
3121682 2032ES/2632ES 151
FIGURE 4-1. PLATFORM INSTALLATION WITHOUT LSS
ITEM PART NUMBER QTY DESCRIPTION REV
1001177177 Ref PLATFORM INSTALLATION WITHOUT LSS B
1 0561520 4 Block, Slide
3 0701024 2 Bolt M10 X 80
4 0701027 2 Bolt M10 X 100
5 0761014 4 Bolt M10 X 30
6 2540045 1 Grommet
8 3291005 8 Nut M10
9 3423049 4 Pin, Latch
12 4812000 12 Washer M10
14 1001175188 2 Bracket, Stop
15 1001175462 1 Platform & Extension Assembly (See PLATFORM AND
EXTENSION ASSEMBLY for Breakdown)
17 1001182302 1 Latch Assembly (See LATCH ASSEMBLY for Breakdown)
