SECTION 2 - GROUND COMPONENTS
3121682 2032ES/2632ES 83
FIGURE 2-15. BATTERIES INSTALLATION - AGM AND EVG TYPE - 225 AH RATING (UL LOCKING
COVERS)
ITEM PART NUMBER QTY DESCRIPTION REV
1001159192 Ref BATTERIES INSTALLATION - AGM AND EVG TYPE - 225 AH
RATING (UL LOCKING COVERS) A
1 0100051 AR Grease, Terminal
2 0760610 8 Bolt M6 x 20
3 0861678 2 Tray Assembly (See BATTERY TRAY ASSEMBLY - UL for
Breakdown)
4 1671204 2 Cover Assembly (See BATTERY COVER ASSEMBLY - LOCKING
for Breakdown)
5 3574981 2 Plate, Slide Stop (LH)
6 3574984 2 Plate, Slide Stop (RH)
7 4191707 8 Screw M6 x 16
8 4240172 4 Strap, Battery
9 4811700 8 Washer M6
10 1001112112 4 Battery Type EVGC6A-A
11 1001112113 1 Sensor, Temperature
