SECTION 7 - ELECTRICAL
3121682 2032ES/2632ES 257
FIGURE 7-21. CHASSIS HARNESS
ITEM PART NUMBER QTY DESCRIPTION REV
1001178496 Ref CHASSIS HARNESS A
1 4460260 2 Housing, Terminal
2 4460320 1 Plug, Male 2 Position
3 4460374 1 Plug, Relay
4 4460539 2 Plug, Male - 3 Position
5 4460648 1 Connector, Anderson
6 4460873 1 Connector - 35 Position (Black)
7 4460884 2 Plug, Male - 4 Position
8 4460894 1 Plug, Male - 6 Position
9 4460897 4 Receptacle, Female - 2 Position
10 4460899 1 Recetacle, Female - 6 Position
11 4460931 1 Receptacle, Female - 8 Position
12 4460986 2 Terminal, Ring
13 1001096138 1 Connector - 23 Position
14 1001097347 1 Relay
15 4460761 1 Receptacle, Female - 4 Position
16 1001115076 1 Connector - 18 Position
24 4460226 2 Socket, Female
25 4460227 4 Pin, Male
26 4460259 2 Terminal
27 4460375 4 Terminal
28 4460464 18 Pin, Male
29 4460465 28 Socket, Female
30 4460466 9 Seal
31 4460871 38 Socket, Female
32 4460905 20 Seal
33 4460942 2 Socket, Female
34 4460943 3 Pin, Male
35 0840058 1 Boot
