SECTION 5 - CYLINDER
178 2032ES/2632ES 3121682
FIGURE 5-1. LIFT CYLINDER ASSEMBLY - 2032ES WITH STANDARD HYDRAULIC OIL (USA BUILT
MACHINES)
ITEM PART NUMBER QTY DESCRIPTION REV
1001155841 Ref LIFT CYLINDER ASSEMBLY - 2032ES WITH STANDARD
HYDRAULIC OIL (USA BUILT MACHINES) C
1 70004725 1 Cylinder Assembly Less Powerpack
2 70004724 1 Seal Kit
3 70004723 1 Barrel
3A 0962257 2 Bushing
4 70004722 1 Rod Assembly (Includes Items 2 & 4A)
4A 0962257 1 Bushing
5 70004943 1 Motor/Pump/Tank Assembly (Includes Items 102-138)
102 70004914 1 O-Ring
103 70004915 1 Cartridge, Valve (Main Relief)
104 70004916 1 Cartridge, Valve (Breather Vacuum Check)
105 70004917 1 Cartridge, Valve (Breather Pressure Check)
106 2220883 6 Plug
107 70004918 2 Pin, Dowel
108 See Note NSS Motor (Note: Not Available - Purchase Complete Assembly)
109 See Note 1 Adapter Assembly (Includes Adapter Plate, Coupling and
Attaching Hardware (Note: Not Available - Purchase Complete
Assembly)
110 70003693 1 Pump (Note: No Serviceable Parts Available - Purchase
Complete Pump)
111 70003694 2 Washer M8
112 70004919 2 Capscrew M8 x 60
113 70004940 1 Tank
114 70004921 2 Plug
115 70004922 4 Bolt M6 x 12
116 70004923 4 Capscrew M10 x 140
117 70004924 4 Washer M10
118 70004925 2 O-Ring
119 70003028 1 Cartridge, Solenoid Valve Less Coil (Steer)
120 70004926 1 Cartridge, Solenoid Valve Less Coil (Lift)
121 See Note 1 Cartridge, Solenoid Valve (Platform Lowering) (Note: Cartridge
and Coil Not Available at Time of Printing)
122 70004927 2 Cartridge, Valve (Steer Relief)
123 70004585 1 Cartridge, Valve (Lift Check)
124 70004928 1 Filter 300 micron
125 70003706 2 Filter 300 micron
126 70003704 2 Seal
127 70004929 2 Fitting, Straight BSPP/UNF
128 See Note 2 Cap
129 70003707 3 Coil
130 70004930 1 Ring, Copper
131 70004931 1 Strainer, Suction
132 70004941 1 Pipe, Suction
133 70004933 1 Fitting
134 70004942 1 Pipe, Return
135 70004935 1 Filter, Bypass
136 See Note NSS Platform Lowering Kit (Note: Not Available for Purchase)
137 70004936 3 O-Ring
138 70004937 2 Pin, Dowel
