SECTION 2 - GROUND COMPONENTS
3121682 2032ES/2632ES 55
FIGURE 2-1. GROUND CONTROL BOX/ALARM INSTALLATION - NO LSS (USA BUILT MACHINES)
ITEM PART NUMBER QTY DESCRIPTION REV
1001166823 Ref GROUND CONTROL BOX/ALARM INSTALLATION - NO LSS A
Ref Note: Standard Alarm located on LH side of operators position on
machine. Optional Alarms are located on the RH Side of operators
position on machines. For optional alarm components, see
SPECIAL OPTIONS Section.
1 1001166194 1 Ground Control Box Assembly (See GROUND CONTROL BOX
ASSEMBLY - NO LSS for Breakdown)
2 0140043 1 Alarm
2 4460536 1 Receptacle, Female - 3 Position
2 4460464 3 Pin, Male
4 0700615 3 Bolt M6 X 35
5 4191706 2 Screw M6 X 12
