SECTION 8 - DECALS
3121682
2032ES/2632ES
301
FIGURE 8-2. DECAL INSTALLATION - AUSTRALIAN SPEC (ENGLISH)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001181270
Ref
DECAL INSTALLATION - AUSTRALIAN SPEC (ENGLISH)
A
Ref
Note: See DECAL INSTALLATION - OPTIONS for additional
decals
1
4751400
8
Washer 1/4
2
0860520
1
Box, Manual Storage
3
3311405
4
Nut 1/4-20
5
2080057
4
Fastener
7
0641406
4
Bolt 1/4 x 3/4
8
2902267
1
Decal Kit - Master (Standard Decals) (Includes item 9-19 & 44)
B
9
1704412
1
Decal - Hydraulic Oil
10
1705693
1
Decal - Safety Prop
11
1704016
2
Decal - Forklift
12
1702155
1
Decal - Battery Disconnect
13
1701509
1
Decal - Manual Reference
14
1703811
4
Decal - Lifting Lugs
15
1703814
3
Decal - Tie Down
16
1704277
3
Decal - Lanyard Attach
17
1703819
4
Decal - Directional Arrow
18
1703822
1
Decal - Manual Descent Instructions
19
1705692
1
Decal - Control Box Location
20
2902523
1
Decal Kit - Australian Spec (Includes Items 21, 22 & 27)
2
21
1705673
4
Decal - Crushing
22
1705671
5
Decal - Electrocution
27
1705670
2
Decal - Warning Battery Ventilation/Fire Hazard
44
1701499
1
Decal - No Lift (Part of Item 8)
46
1001094359
1
Decal - Troubleshooting
47
1001146794
2
Decal - See Manual
